Power Oxidizer 2 MW (KG2-3GEF/PO) Powerstation

The Dresser-Rand Power Oxidizer 2 MW (KG2-3GEF/PO) Powerstation’s gas turbine with Ener-Core Power Oxidizer technology is the only clean power generation that runs directly on lowpressure, low-quality gases that otherwise could not be used. The system integrates oxidation technology with the field proven 2MW-KG2-3G gas turbine, to efficiently generate electricity with near-zero emissions. The Power Oxidizer 2 MW (KG2-3GEF/PO) Powerstation’s gas turbine’s wide fuel range enables operation on extremely low-grade or waste fuels, landfill gas, biogas, coal gas, and associated petroleum gas. Its ability to maintain near-zero emissions excels in regulated air quality markets without additional emissions controls. The Dresser-Rand KG2-3G gas turbine is the preferred solution for clean power requirements from 1 to 12 MW with nearly 1,000 installed units with more than 25 million operating hours.

Features And Benefits Of The Power Oxidizer 2 MW (KG2-3GEF/PO) Powerstation

  • Class-leading fuel efficiency.
  • High effectiveness recuperator.
  • Wide fuel spec tolerance.
  • Ultra-low NOx emissions, < 1 ppmv.
  • No catalyst or chemicals used.
  • H2S acceptance.
  • Siloxane tolerant.

Click Here For Ener-Core Power Oxidizer 2 MW (KG2-3GEF/PO) Powerstation Product Info Sheet

Fuel Operating Range (HHV) 25 - 2,600 Btu/scf (0.93 - 97 MJ/m3)
Nominal Electrical Output 1,850 kW (±30kW)
Nominal Heat Rate (LHV) 9,750 Btu/kWh (10,286 kJ/kWh)
Electrical Efficiency (LHV) (±2) 35% (±2)
System Footprint 105,000 lb (47,627 kg)
Achievable NOx Emissions <1 ppm @15% O2 (dry basis)
Achievable VOC Destruction Efficiency Up to 99% DRE (depending on process conditions)
